Customized Prefabricated Steel Warehouse with 30 Meters Span and 50 Years Service Life
| MOQ: | 1 PCS/20 Tons |
| Price: | $1300-3000 |
| Standard Packaging: | Customized based on project |
| Delivery Period: | 30-60 Days |
| Payment Method: | L/C,D/A,D/P,T/T |
| Supply Capacity: | 15000 Tons |
Detail Information
Place of Origin
Chengdu , China
Brand Name
Sichuan Shunyao Supply Chain Management Co., Ltd.
Certification
CE,ISO
Lifting Capacity:
10-ton To 32-ton
Span Range:
Up To 30 Meters Without Internal Columns
Max Wind Resistance:
250 Km/h
Frame Material:
Cold-formed Steel / Hot-rolled Steel
H Beam Range:
Height 200-1,200 Mm; Web 6-32 Mm; Flange 6-40 Mm; Length 4,000-15,000 Mm
Roof Live Load:
120 Kg/m²
Highlight:
Customized Design Steel Warehouse
,30 Meters Span Prefabricated Steel Building
,50 Years Service Life Steel Frame Building
Product Description
Customized Prefabricated Steel H-Beam Warehouse
Custom Design & Engineering
We build steel warehouses to order. Send a drawing, or the building size and the loads it has to carry, and we manufacture the H-section frame, purlins, panels and fixings to suit. Everything is prefabricated in our workshop and bolted together on site—no on-site welding required.
Built to Your Specifications: Size, roof slope, eave height, color, door and window style are all set by the buyer. If you have drawings, we fabricate to them. If not, our engineers draft the layout from your requirements and send it for approval before production begins.
Section shape can be straight or tapered (variable cross-section) to suit the span and load requirements. We can also develop custom parts from customer drawings for projects needing non-standard components.
Main Frame Components
- Columns and rafters: Welded H-section steel in Q235B or Q345B, all-bolted connections
- Bracing: X-type, V-type or other configurations, made from angle steel or round pipe
- Purlins: C120-C320 or Z100-Z200 cold-formed sections
- Knee braces: Q235 angle steel
- Tie bars: Q235 steel pipe
- Foundation: Concrete with steel anchor bolts—set out to the foundation drawing we supply
H-Beam Specifications
- Height: 200-1,200 mm
- Web plate: 6-32 mm
- Flange plate: 6-40 mm
- Length: 4,000-15,000 mm
- Material: Q235B, Q345B, or as specified by buyer
- Dimensional tolerance: ±1%
- Bolts: Plain bolts and high-strength bolts
- Quality system: ISO 9001
Building Configuration Options
- Roof: Single slope, double slope or multi-slope
- Span: Single-span, double-span or multi-span
- Storeys: Single or two floors
- Size: Quoted as width × length × eave height, with roof slope set for your site
Cladding & Accessories
- Roof and wall: Single color steel sheet 0.326-0.8 mm (YX28-205-820 profile, 820 mm cover width), or sandwich panels—EPS, rock wool or PU, 50-150 mm thick, 950/960 mm wide
- Galvanized sheet: 0.5 mm or 0.6 mm
- Accessories: Semi-transparent skylight belts, ventilators, downpipes and outer gutter (stainless steel or color steel). Downpipes are PVC
- Doors: Swing, sliding or roller
- Windows: Aluminum or PVC push-pull
- Partition walls: Sandwich panels in various colors and thicknesses as needed
Surface Treatment
Two coats of anti-rust paint—grey, red, white or epoxy zinc—or hot-dip galvanizing. The finish is chosen for the site conditions: galvanizing for coastal or humid locations, paint where appearance matters most. Colors and textures are customized to buyer requirements.
Design Loads & Service Life
- Roof live load: 120 kg/m² with sheet-clad roof
- Wind resistance: Grade 12 by Chinese classification. Designed for 60-300 km/h based on location
- Seismic: Grade 8-9
- Service life: Up to 50 years
- Design standards: GB, ASTM, DIN, BS, JIS or AISI, as specified in your drawings
Technical Specifications
| Item | Specification |
|---|---|
| Building type | Customized prefabricated steel warehouse / workshop |
| Main frame | Welded H-section steel, Q235B / Q345B, all-bolted |
| H beam range | Height 200-1,200 mm; web 6-32 mm; flange 6-40 mm; length 4,000-15,000 mm |
| Section shape | Straight or tapered (variable cross-section) |
| Tolerance | ±1% |
| Purlins | C120-C320 / Z100-Z200 cold-formed sections |
| Bracing | X-type / V-type, angle steel or round pipe |
| Roof & wall | Color steel sheet 0.326-0.8 mm, or sandwich panel (EPS / rock wool / PU) 50-150 mm |
| Galvanized sheet | 0.5 mm / 0.6 mm |
| Doors / Windows | Swing / sliding / roller door; aluminum or PVC push-pull window |
| Gutter / Downpipe | Stainless or color steel gutter; PVC downpipe |
| Surface treatment | Two coats anti-rust paint (grey / red / white / epoxy zinc) or hot-dip galvanized |
| Roof live load | 120 kg/m² (sheet-clad roof) |
| Wind resistance | Grade 12; designed to 60-300 km/h by site |
| Seismic | Grade 8-9 |
| Service life | Up to 50 years |
| Standards | GB, ASTM, DIN, BS, JIS, AISI |
| Quality system | ISO 9001 |
| Packing | Main frame in 40ft open-top; panels in 40ft high-cube |
| Place of origin | Chengdu, Sichuan, China |
| HS Code | 7308900000 |
Design Requirements
If you would like us to design the building, please provide the following information along with detailed sizes:
- Roof live load, in kN/m²
- Wind speed, in km/h
- Snow load, in kg/m², if applicable to your site
- Earthquake load, if the site is in a seismic zone
- Crane specifications (if needed)—span, lift height, maximum lift capacity, and maximum/minimum wheel pressure
Design work is provided free of charge.
Applications
- Warehouses and storage buildings
- Workshops and factories
- Garages
- Light industrial buildings
- Other custom steel frame buildings
