Smart Agricultural Greenhouse Structure-Modular Prefabricated Steel Frame Building for Environment Farming
| MOQ: | 1 PCS |
| Price: | $20-40 |
| Standard Packaging: | Bundles |
| Delivery Period: | 5-15 days |
| Payment Method: | T/T |
| Supply Capacity: | Excellent |
Our smart agricultural greenhouse structure is a modular prefabricated steel frame solution, engineered to enable precision environmental farming and optimize crop production in diverse climates. With customizable dimensions (6–15m width, 3–8m height, 20–100m length), this greenhouse can be tailored to fit any farm size or cultivation requirement, from small-scale nurseries to large commercial vegetable farms.
Built with a hot-galvanized steel frame, the structure delivers exceptional corrosion resistance and durability, withstanding the harsh conditions of agricultural operations. The covering system uses high-quality PEP/PO plastic film (single or double layer), offering excellent light transmission and weather protection, with material thickness options (1.5mm or 2mm) to adapt to different climate zones.
Designed to meet strict load requirements (0.4KN/m² snow load, 0.5KN/m² wind load, 140mm/h rainfall load), this greenhouse ensures stability and safety even in extreme weather. Equipped with essential accessories like lock channels and wiggle wires for secure membrane installation, it provides a controlled environment for hydroponics, seedling growth, and year-round crop cultivation, making it the ideal choice for modern farmers and agricultural enterprises seeking smart, sustainable, and high-yield farming solutions.
| Product Name | Smart Agricultural Greenhouse Structure – Modular Prefabricated Steel Frame Building for Environmental Farming |
| Dimensions | - Width: 6m–15m (customizable) - Height: 3m–8m (customizable) - Length: 20m–100m (customizable) |
| Frame Structure | Hot-galvanized steel structure (corrosion-resistant, durable for agricultural environments) |
| Covering Material | Plastic Film (PEP/PO), single or double layer membrane (light-transmitting, weather-resistant) |
| Material Thickness | 2mm or 1.5mm (flexible options for different climate requirements) |
| Arch Specification | 40*1.5mm or 48*1.5mm (high-strength support for the greenhouse frame) |
| Standard Accessories | Lock channel, wiggle wire, and other hardware for secure membrane installation |
| Load Capacity | - Snow Load: 0.4KN/m² - Wind Load: 0.5KN/m² - Rainfall Load: 140mm/h (resilient to extreme weather) |
| Core Applications | Precision environmental farming, hydroponics, seedling nurseries, vegetable cultivation, and smart agricultural production |
