Hot Dip Galvanizing Steel Building Supports Reusable Customizable
| MOQ: | 100 PCS |
| Price: | $15-50 |
| Standard Packaging: | Bundles |
| Delivery Period: | 5-15 days |
| Payment Method: | T/T in advance |
| Supply Capacity: | Excellent |
Detail Information
Place of Origin
Chengdu , China
Brand Name
Shunyao Supply Chain
Warranty:
5 Years
Thickness Of Panel:
50mm, 75mm, 100mm, 150mm, 200mm, 250mm
Connection:
Bolts
Design Load:
Wind, Snow, Seismic
Raw Steel Material:
Q235B, Q355B
Maintenance Costs:
Reduced
Corrosion Resistance:
High
Labor Costs:
Lower
Using Life:
50 Years
Highlight:
Hot Dip Galvanizing Steel Building Supports
,Reusable Steel Building Supports
,Customizable Steel Concrete Support
Product Description
Main Product Name: Steel Structural Building Support; Other Names: Building Steel Support, Prefabricated Steel Support, Steel Structural Load-bearing Bracket; Keywords: Steel Support, Building Load-bearing Structure, Prefabricated House Support, Steel Mezzanine Bracket, Construction Temporary Support.
Processing Technology: CNC flame cutting (dimensional accuracy ±0.5mm), submerged arc automatic welding (weld strength qualification rate 100%), shot blasting derusting (derusting grade up to Sa2.5), hot-dip galvanizing/painting anti-corrosion, ultrasonic flaw detection (ensuring no weld defects);
Load-bearing Parameters: Single vertical bearing capacity 50kN - 1000kN, customizable according to material and cross-sectional dimension (e.g., φ48*3.5mm steel pipe support has a bearing capacity of about 50kN, 300*300mm H-beam support can reach 1000kN);
Anti-corrosion Standards: Hot-dip galvanized layer thickness ≥85μm, salt spray test ≥1000h; painting anti-corrosion adopts epoxy primer + polyurethane topcoat, dry film thickness ≥120μm, salt spray test ≥800h;
| Material | Steel | Application | Residential, commercial, and public buildings | |
| Feature | High Strength, Easily Assembled, Reusable |
Warranty | 2 Years | |
| Design Style | Traditional | After-sale Service | Online Technical Support, Onsite Installation |
|
| Project Solution Capability |
3D model design, graphic design |
Place of Origin | Chengdu, China | |
| Brand Name | Shunyao supply chain steel frame | Function | Diversified Agricultural Needs | |
